Homepage >> Product Detail

CE Approved 12 inch alloy wheel 200CC ATV Equipped with Powerful water Cooling

Item NO.:	AT2001
Category:	Gas ATV
Update:	6/26/2015 2:07:12 AM

Inquire

More Pictures:

Product Discription:

ATV
CE Approved 12 inch alloy wheel 200CC ATV Equipped with Powerful water Cooling Engine
AT2001-A
Key Specifications:
1. Wheel number: 4
2. Piston displacement: 200cc
3. Engine type: single cylinder, water-cooled
4. Starting system: electric
5. Fuel tank capacity:8L
6. Drive train: chain
7. Ignition method: CDI
8. Max.power 13.0kw/7,500rpm
9. Max.Torque: 17.5N.m/5,000rpm
10. Brakes: (Front/Rear)Disc/Disc
11. Transmission: manual clutch,4-speed,reverse gear,chain
12. Battery spec:12V,9AH
13. Front suspension detail:double A x swing arm;air chamber shock absorber
14. Rear suspension detail:divided ballonet absorber
15. Wheel side: front: 185x30-14, rear: 270x30-14
16. Vehicle dimension:195x118x110cm
17. Wheel base:140cm
18. Seat height from ground:67cm
19. Min. ground clearance: 80mm
20. Loading capacity:370kgs
Package: Iron cage with carton outside
21. Net weight: 190kgs
22. Gross weight: 220kgs
23. Carton size: 170x112x75cm/1pc
24. Container: 18pcs/20’, 42pcs/40’HQ

ATV
CE Approved 12 inch alloy wheel 250CC ATV Equipped with Powerful water Cooling Engine
AT2001-B
Key Specifications:
25. Wheel number: 4
26. Piston displacement: 250cc
27. Engine type: single cylinder, water-cooled
28. Starting system: electric
29. Fuel tank capacity:8L
30. Drive train: chain
31. Ignition method: CDI
32. Max.power 13.0kw/7,500rpm
33. Max.Torque: 17.5N.m/5,000rpm
34. Brakes: (Front/Rear)Disc/Disc
35. Transmission: manual clutch,4-speed,reverse gear,chain
36. Battery spec:12V,9AH
37. Front suspension detail:double A x swing arm;air chamber shock absorber
38. Rear suspension detail:divided ballonet absorber
39. Wheel side: front: 185x30-14, rear: 270x30-14
40. Vehicle dimension:195x118x110cm
41. Wheel base:140cm
42. Seat height from ground:67cm
43. Min. ground clearance: 80mm
44. Loading capacity:370kgs
Package: Iron cage with carton outside
45. Net weight: 190kgs
46. Gross weight: 220kgs
47. Carton size: 170x112x75cm/1pc
48. Container: 18pcs/20’, 42pcs/40’HQ

http://youtu.be/siUC2JHLWyg
