| Wheel number: 4
Piston displacement: 50cc/70cc/90cc/110cc
Engine: single-cylinder, 4-stroke, air-cooling
Starting system: CDI electric start
Battery:12V 4AH
Fuel tank volume: 5L
Drive system: chain dive
Brake: Front: drum brake; Rear: disc brake
Max speed: 40km/h
Load capacity: 150kgs
Rated power: 2.0Kw/8000r/min
Rated torque: 2.6N.m/5000r/min
Wheel: front and rear 145/70-6
Max torque: 4.2Nm/5000rpm , 4.2Nm/5000rpm, 5.2Nm/5000rpm, 5.5Nm/5000rpm
Max power:
3.0Kw/8500rpm,3.0kw/7500rpm,3.3kw/7500rpm,3.6kw/7500rpm
Front suspension details: double A x swing arm
Rear suspension details: mono shock swing arm
Product Size: 141x97x100cm
Wheel base: 940mm
Seat height from ground: 70cm
Ground clearance: 110mm
Package: Iron cage with carton outside
Net weight: 108kgs/237.6lbs
Gross weight: 116kgs/255.2lbs
Carton size: 131X84X66cm/1pc
Container: 30pcs/20’, 92pcs/40’HQ
|
