Homepage >> Product Detail

CE Approved 200CC ATV Equipped with Powerful Engine

Item NO.:	AT2002
Category:	Gas ATV
Update:	6/26/2015 2:06:41 AM

Inquire

More Pictures:

Product Discription:

ATV
CE Approved 200CC ATV Equipped with Powerful Engine
AT2002-A
Key Specifications:
1. Wheel number: 4
2. Piston displacement: 200cc
3. Engine type: single cylinder,
4. Starting system: electric
5. Fuel tank capacity:11L
6. Drive train: chain
7. Ignition method: CDI
8. Max.power 10.0kw/7,500rpm,11.0kw/7500rpm
9. Max.Torque: 13.5N.m/5,500rpm, 17.5N.m/5,000rpm
10. Brakes: (Front/Rear) Drum/Drum(for shaft),Disc(for chain)
11. Transmission: manual clutch,4-speed,reverse gear,chain/shaft drive
12. Battery spec:12V,9AH
13. Front suspension detail:double A x swing arm
14. Rear suspension detail:mono shock swing arm
15. Wheel side: front: 23x7-10, rear: 22x10-10
16. Vehicle dimension:208x124x113cm
17. Wheel base:116cm
18. Seat height from ground:90cm
19. Min. ground clearance: 155mm
20. Loading capacity:165kgs
Package: Iron cage with carton outside
21. Net weight: 206kgs
22. Gross weight: 228kgs
23. Carton size: 194x109x84cm/1pc
24. Container: 12pcs/20’, 24pcs/40’,36pcs/40’HQ

ATV
CE Approved 200CC ATV Equipped with Powerful water-cooled Engine
AT2002-B
Key Specifications:
25. Wheel number: 4
26. Piston displacement: 200cc
27. Engine type: single cylinder, water-cooled
28. Starting system: electric
29. Fuel tank capacity:11L
30. Drive train: chain
31. Ignition method: CDI
32. Max.power 10.0kw/7,500rpm,11.0kw/7500rpm
33. Max.Torque: 13.5N.m/5,500rpm, 17.5N.m/5,000rpm
34. Brakes: (Front/Rear) Drum/Drum(for shaft),Disc(for chain)
35. Transmission: manual clutch,4-speed,reverse gear,chain/shaft drive
36. Battery spec:12V,9AH
37. Front suspension detail:double A x swing arm
38. Rear suspension detail:mono shock swing arm
39. Wheel side: front: 23x7-10, rear: 22x10-10
40. Vehicle dimension:208x124x113cm
41. Wheel base:116cm
42. Seat height from ground:90cm
43. Min. ground clearance: 115mm
44. Loading capacity:165kgs
Package: Iron cage with carton outside
45. Net weight: 206kgs
46. Gross weight: 226kgs
47. Carton size: 194x109x84cm/1pc
48. Container: 12pcs/20’, 24pcs/40’,36pcs/40’HQ
